CloudOptics Active Optical Cables (AOC) accelerate storage, data, and high-performance computing connectivity. Our complete product line includes SFPwire AOC for 10/25GbE; Quadwire AOC for 40/100GbE, InfiniBand QDR/FDR/EDR, SAS3 and PCIe3; and C.wire AOC for 100GbE and beyond. Each cable solution leverages CloudOptics fiber optic technology for the transmission of data while reducing the weight, density and power consumption compared to traditional copper solutions.
How To BuyContact us
sales@cloudoptics.net
| Item | Max Data Rate | Minimum Bend Radius | Jacket Material | Temperature | Protocols |
| 10G SFP+ AOC Cable | |||||
| CO-10GSFP+-AOC1M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC2M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC3M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC5M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC7M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC10M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC15M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC20M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC25M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC30M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC50M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC75M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| CO-10GSFP+-AOC100M | 10Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
| 25G SFP28 AOC Cable | |||||
| CO-25GSFP28-AOC1M | 25Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-25GSFP28-AOC3M | 25Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-25GSFP28-AOC5M | 25Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-25GSFP28-AOC7M | 25Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-25GSFP28-AOC10M | 25Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-25GSFP28-AOC15M | 25Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-25GSFP28-AOC20M | 25Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-25GSFP28-AOC30M | 25Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-25GSFP28-AOC50M | 25Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-25GSFP28-AOC100M | 25Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| 40G QSFP+ AOC Cable | |||||
| CO-40GQSFP+-AOC1M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC2M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC3M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC5M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC7M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC10M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC15M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC20M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC25M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC30M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC50M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+-AOC100M | 40Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| 40G QSFP+ to 8x LC AOC Cable | |||||
| CO-40GQSFP+/8LC-AOC1M | 40Gbps | 3mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+/8LC-AOC3M | 40Gbps | 3mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+/8LC-AOC5M | 40Gbps | 3mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| CO-40GQSFP+/8LC-AOC10M | 40Gbps | 3mm | OFNP | 0 to 70°C (32 to 158°F) | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
| 100G QSFP28 AOC Cable | |||||
| CO-100GQSFP28-AOC1M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC2M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC3M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC5M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC7M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC10M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC15M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC20M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC25M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC30M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC50M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
| CO-100GQSFP28-AOC100M | 100Gbps | 7.5mm | OFNP | 0 to 70°C (32 to 158°F) | |
